WaterWeights 12.5 Tonne Proof Load Test Bag – Rental
SKU: WW-RENTAL-12-5T

WaterWeights 12.5 Tonne Proof Load Test Bag – Rental

$0.00Price
Quantity

The 12.5 tonne WaterWeights Low Headroom bag is the largest bag in the Low Headroom range, giving a high test load in limited height. It suits overhead and gantry cranes, monorails, hoists and davits.


WaterWeights water-filled proof load test bags are a safer, more flexible alternative to solid test weights. The load is raised gradually and under control, so any problem shows up before the full test load is reached. An empty bag weighs only a small fraction of its test load, so it ships, handles and stores easily, and it is filled with water on site.


Specifications (Type BS 125L – Low Headroom):

- Safe working load (test capacity): 12.5 t

- Filled height (overall, to lifting point): approx. 14.5 ft (4.42 m)

- Filled maximum diameter: approx. 10 ft (3.05 m)

- Packed size (L x W x H): 1.00 x 1.20 x 0.80 m (approx. 3.3 x 3.9 x 2.6 ft)

- Packed weight: 185 kg (approx. 408 lb)

- Net (empty bag) weight: 150 kg (approx. 331 lb)

- Empty height: 4.80 m (approx. 15.7 ft)

- Filling connection: 2.5" Storz

- Use: One bag per lifting point. Combine bags with a spreader beam.


Specifications shared by all our WaterWeights bags:

- Safety factor: 6:1, NEL certified

- Proof tested: every bag is physically proof tested at 2:1

- Skin material: PVC-coated polyester fibre canvas

- Maximum wind speed in use: 25 knots

- When a bag is filled below full capacity, its diameter gets smaller and its length increases.


Rent the bag on its own for your own qualified crew, or book SafeLift Crane Aid to carry out the complete load test and certification. Tell us the rated capacity of your equipment, the test load you need, the available headroom, your site location and your dates, and we will recommend the right bags and confirm availability, rates and shipping.


Optional rental add-ons: calibrated flow meters or load cells, and water pumps, are also available for rent. Contact us for rental rates.


In stock in Langham, ready to ship across Canada. Rental only – contact us for rates and availability: +1 (306) 374-5476 | sales@ventercranes.com


Filled height and diameter are taken from the general arrangement drawings of our own rental bags; other specifications are from WaterWeights published data. All dimensions are approximate. Ask us for the specifications of the bag you are renting.
